ACBOX Module


Product Features

The Philips PXL4-4-2 modular distribution box features a dual-layer layout to facilitate organized wiring and easy maintenance.
Equipped with high-performance circuit breakers, it provides reliable overload and short-circuit protection to safeguard electrical equipment.
Its flame-retardant, impact-resistant housing ensures a long service life for home, retail, and office applications.
Backed by strict original quality control, it delivers stable power distribution performance for indoor scenarios.

Specification Parameters

Category	Parameter	Value
General Parameters	Dimension [W / D / H]	296 mm × 230 (460) mm × 490 mm
Performance	Rated AC V	380/400/415V, 220/230/240V, L1/L2/L3/N+PE
	Grid Max I	63 A
	Inv Max I	60 A
	Backup Max I	63 A
	Non-backup Max I	63 A
	LVRT	Support
	Grid Switch Time	≤20ms (MAP0), ≤100ms (M1/MB0) ²
	Bypass Switch Mode	Manual
	Generator Mode	Remote Control
Measurement Range	Current Range	≤ 63 A
Measurement Range	Energy Measurement Accuracy	± 1 %
Operating Environment	Cooling Method	Natural Cooling
	RH Range	5% ~ 95% RH (Non-condensing)
	Operating Altitude	4000m (Derating above 2000m)
	IP Rating	IP55
	Operating Temperature	-25℃ ~ 50℃
